Sidelight 1.5W SMD2835 Led Signage Module

Product Name:  Sidelight 1.5W SMD2835 Led Signage Module

Model:  SYM-2835SL-1.5W

brief:  For kinds of Lighting box.

Enquiry:


Products Feature:
●Adopting SMD2835 as light source---with high luminous Flux & color consistance
●Best sealed IP65 with moisture-proof, waterproof, dustproof and impact resistance
●Adopting PVC injection molding technology, with nice structure & design

Application:
●15-25cm thickness big size light box side lighting.
●Best for 15cm depth double side light box,max distance is 1.5m.





Installation
●Clean & remove all debris from the inside of signage/lightbox
●Position the module with double sided tape and stick on the back of board
●Potting glass glue on both side of led module or screwing is recommended as security.
●Use screws ,or silicon to secure at least every fifth LED module within the channel letter
